Product Image
Bi-Metal 4" Straight Splice
Product Information
Product Variations
| Product No. | Material | Box Qty. | Approx. Box Wt. (lbs.) | Documents | |
|---|---|---|---|---|---|
| 211R | Aluminum / Brass | 10 | 4.25 |
|
• Approximately 4" long, four bolt bi-metal connector provides a non-electrolytic connection between copper and aluminum conductors.
• Brass side accepts all main size conductors up to .53” diameter.
• Aluminum side accepts all main size conductors up to .59” diameter.
• Four 5/16" hex head stainless steel cap screws assure a positive electrical connection.
• Recommended installation tool - 1/2" socket wrench, end wrench or nut driver.
